DIY 9-Ton Hydraulic Punch Driver Tool Kit w/ 6 Dies Blue

This completely hydraulic punch driver kit will help you make the perfect hole! Forget the old, wrench-style punches, this one can exert up to 9 tons of pressure and will make any job a breeze! It's designed to punch perfect holes in plastic, aluminum and steel. Just right for maintenance, construction and electrical work!

SPECIFICATIONS

• 6 Dies & Punches Interchangeable to drill different sizes holes on stainless steel, aluminum, steel, plastic, etc
• Hydraulic mechanism of the pump produces a strong force of 9T for providing great punching accuracy and fast punching speed which is 10 times much faster than common wrenches
• 40Cr steel dies and 45# steel pump body for ensuring high strength, sturdiness and durability, stable construction
• Rotatable "on/off" knob on the pump for quick releasing pressure after drilling holes and safety valve for releasing pressure automatically when the pressure reaches the max value
• Anti-skid plastic grip at the end of the handle for easy and comfortable pressing
• Easy Seating with the Brackets on the Bottom of the Hydraulic Pump
• Blow-molded plastic case with handle for providing portability and convenient storage
• Widely used on installing and repairing wire pipeline, signal lamp and instrument on construction sites, metallurgy, petrol, electronics, electrical appliance, chemical industry, ship and machinery, etc.

QUICKIE GUIDE:

• Pump Dimension(LxWxH): 12 5/8" x 4 5/16" x 4 5/16" (32 x 11 x 11 cm)
• Plastic Case Dimension(LxWxH):   16 15/16" x 9 7/16" x 4 3/4" (43 x 24 x 12 cm)
• Draw Stud Sizes(LxDia.): 3 1/8" x 5/16" (7.9 x 0.8 cm), 3 3/16" x 5/16" (8.1 x 0.8 cm)
• Max Pressure: 9 ton
• Max Thickness for Iron: 1/8" ( 11 gauge )
• Max Thickness for Stainless Steel: 1/16" ( 14 gauge )
• Ram with 31" High Pressure Hose
• Material: 45# Steel, 40Cr Steel
• 6 x Dies and Punches : 1/2", 3/4", 1", 1 1/4", 1 1/2", 2"
• 2 x Draw Studs: 3.1"L x 0.31"Diam and 3.2"L x 0.3"Diam
• Net Weight: 20.9 Lbs (9.5 kg)

Corresponding Size:

Actual Hole Size	Dies & Punches Size
0.885" (22.5mm)	1/2"
1.115" (28.3mm)	3/4"
1.362" (34.6mm)	1"
1.701" (43.2mm)	1 1/4"
1.951" (49.6mm)	1 1/2"
2.416" (61.5mm)	2"

NOTICE: Do Not Operate The Pump After Ram Motion Stops. Continuing to Operate The Pump Lever After The Ram Stops Will Damage The Ram.
